Ultimate Ground Clearance

The TRX-4 Scale and Trail Crawler is equipped right out of the box with Traxxas' game-changing portal axle set. Portal axles lift the truck at the wheels for huge center pumpkin ground clearance. In order to achieve the same clearance with straight axles (and not get stuck), your tires would have to be over an inch taller than the TRX-4's tires. Straddling boulders with ease, the TRX-4 chassis definitely takes the path less travelled and simply leaves all the others behind.

TRX4 2022 BRONCO - ORANGE

After 25 years, the Bronco returns as Ford’s top-performing 4X4 and America’s most sought-after SUV. Traxxas captures the eagerly-anticipated Bronco in exacting detail with all the capability and versatility of the award-winning TRX-4. The Traxxas Bronco combines Ford-approved realism and class-leading performance for exciting off-road adventure no matter where the trail takes you.

Length (overall): 584mm
Length (chassis): 549mm
Front Track: 249mm
Rear Track: 249mm
Ground Clearance: 80mm
Weight: 2.91kg
Height: 239mm
Wheelbase: 324mm
Front Shock Length: 90mm
Rear Shock Length: 90mm
Front Wheels: 49 x 26mm
Rear Wheels: 49 x 26mm
Front Tires: 118 x 48mm
Rear Tires: 118 x 48mm
Approach Angle: 52°
Departure Angle: 49°
Breakover Angle: 58°
Hex Size: 12mm
Speed Control: XL-5 HV
Motor (electric): 21T Reverse Rotation
Transmission: 2-speed Hi-Lo, Remote Shifting
Gear Pitch: 32P
Differential Type: 4 Gear, Remote Locking
Chassis Structure / Material: Steel Ladder Frame with Nylon Composite Crossmembers
Brake Type: Electronic “Hill Hold”
Drive System: Shaft Driven 4WD
Steering: Chassis Mounted Servo
Servo: 2075X Metal Gear
Transmitter: TQi™ 2.4 GHz 4-Channel Transmitter
Receiver: 6533
Skill Level: 1
Battery Tray: 158.75 L x 47 W x 23/26mm H
