SPECIFICATIONS

Working voltage: 5.0V-36V
Input voltage 1s : 0.8V-15V
Input voltage 2-8S : 0.8V-4.8V
Battery cells : 1-8S
Voltage measurement accuracy : ±0.005V @ 4.2V
Balancing cells accuracy : < 0.005V
Support USB charging : QC 2.0 / 3.0, BC1.2, Maximum output 12V/2A
Support smart battery : Charging and discharging setting, read battery info and usage history.
Supported Batt. Type : LiHv (1-8S) / LiPo (1-8S) / LiFe(1-8S) / Lilon (1-8S) / NiMH/Cd(1-10S)
Display : 2.4〃320×240 260,000 color IPS LCD
Dimension : 80 X 55 X 19 mm
Weight : 59g
Operating Temperature: 0-40℃
Working Humidity: 10%-90%RH (noncondensing)
Storage Temperature: -20-60℃
Storage Humidity: 5%-90%RH (noncondensing)
Servo PWM Output Hz: 1520uS = 50Hz / 760uS = 333Hz
