Dualsky GA800.11 550KV Brushless Motor, 1000w, 40E
$139.95
SKU:
DSXM51747
Product Description
Overview
Dualsky GA800.11 550KV Brushless Motor, 1000w, 40E
Features
- Designed for 30E - 40E class 3D airplane (Up to 55 inch wingspan)
- Great alternative for a .15-.46ci engine
- New modular light weight structure
- Dualsky 28 poles efficient structure
- Integrated motor mount
Product Information
Dualsky GA800.11 550KV Brushless Motor, 1000w, 40E
Specs
- RPM/V KV
- 550
- Weight w/o accessories
- 160g
- Outer Diameter
- 46 mm
- Length w/ mounts
- 42mm
- Length (overall)
- 74mm
- Diameter of Shaft
- 5mm (internal)
8mm (output) - Mounting holes pitch
- 52mm to 58mm (D 4.2)
- Slots, Poles
- 24, 28
- Idle Current (Io) @10V
- 1.3A
- Resistance (Ri)
- 42.7 mOhm
- Nominal Voltage (V)
- 22.2V, 6S LiPo
- Peak Power [15s]
- 1000W
- Bursts Current [15s]
- 42A
- Cruising Power [8 mins]
- 500W
- Recommended ESC
- XC406ULT
- Propeller
- 12 x 6 for best efficiency
13 x 6.5 for pilots performance
14 x 7 for extreme thrust - Weight of Sports Airplane
- Up to 2.2kg
- Weight of 3D Airplane
- 1.5kg to 1.8kg
